How to Install Coroot on Ubuntu VPS

Here’s a detailed step-by-step guide demonstrating how to install Coroot on Ubuntu VPS.

What is Coroot?

Coroot is an open-source observability tool that helps you monitor and troubleshoot your applications using eBPF. It provides deep insights into service dependencies, performance bottlenecks, and anomalies in real-time.

Prerequisites

Before you begin:

• A VPS with Ubuntu 20.04+
• sudo privileges
• Ports 8080, 3000, and 9090 open (for Coroot, Grafana, and Prometheus)
• Optional: Docker and Docker Compose installed (preferred deployment method)

How to Install Coroot on Ubuntu VPS

To install Coroot on Ubuntu VPS, follow the steps provided:

1. Update Your System

   sudo apt update && sudo apt upgrade -y


2. Install Docker & Docker Compose

   If not already installed:

   sudo apt install -y docker.io docker-compose
   sudo systemctl enable docker
   sudo systemctl start docker


3. Create a Docker Compose File for Coroot

   Create a working directory:

   mkdir ~/coroot && cd ~/coroot


   Create the docker-compose.yml file:

   nano docker-compose.yml


   Paste the following configuration:

   version: '3.7'

   services:
     prometheus:
       image: prom/prometheus
       volumes:
         - ./prometheus.yml:/etc/prometheus/prometheus.yml
       command:
         - '--config.file=/etc/prometheus/prometheus.yml'
       ports:
         - "9090:9090"

     coroot:
       image: ghcr.io/coroot/coroot:latest
       ports:
         - "8080:8080"
       depends_on:
         - prometheus
       environment:
         - PROMETHEUS_URL=http://prometheus:9090


4. Add Basic Prometheus Configuration

   Create a basic prometheus.yml file:

   nano prometheus.yml


   Paste:

   global:
     scrape_interval: 15s

   scrape_configs:
     - job_name: 'prometheus'
       static_configs:
         - targets: ['localhost:9090']


5. Start Coroot and Prometheus

   Now start the services:

   docker-compose up -d


   Verify that all services are running:

   docker ps


6. Access Coroot Dashboard

   Open your browser and go to:
   http://your-server-ip:8080
   You should see the Coroot UI!

7. Optional: Enable eBPF Monitoring (Linux Only)

   Coroot can use eBPF for deep visibility:

   1. Install required dependencies:

      sudo apt install -y linux-headers-$(uname -r) bpfcc-tools


   2. Add the Coroot Node Agent as another service in docker-compose.yml:

        agent:
          image: ghcr.io/coroot/coroot-node-agent:latest
          network_mode: host
          pid: host
          privileged: true
          volumes:
            - /sys:/sys
            - /proc:/proc


   3. Restart the stack:

      docker-compose down && docker-compose up -d


8. (Optional) Add Grafana

   To visualize more metrics:

     grafana:
       image: grafana/grafana
       ports:
         - "3000:3000"
       environment:
         - GF_SECURITY_ADMIN_PASSWORD=admin
       depends_on:
         - prometheus


   Access Grafana at:
   http://your-server-ip:3000
   Default credentials: admin/admin

Notes

• For production, configure Prometheus to monitor your real services.
• Secure your stack with a reverse proxy and SSL (e.g., Nginx + Let’s Encrypt).
• Monitor Docker resource usage with docker stats.

Nginx Reverse Proxy with SSL for Coroot

1. Install Nginx and Certbot

   sudo apt update
   sudo apt install -y nginx certbot python3-certbot-nginx


   Allow HTTP/HTTPS traffic:

   sudo ufw allow 'Nginx Full'


2. Start Coroot Stack

   If you haven’t already:

   mkdir ~/coroot && cd ~/coroot
   nano docker-compose.yml


   Paste this (including Prometheus + Coroot):

   version: '3.7'

   services:
     prometheus:
       image: prom/prometheus
       volumes:
         - ./prometheus.yml:/etc/prometheus/prometheus.yml
       command:
         - '--config.file=/etc/prometheus/prometheus.yml'
       ports:
         - "9090:9090"

     coroot:
       image: ghcr.io/coroot/coroot:latest
       ports:
         - "8080:8080"
       depends_on:
         - prometheus
       environment:
         - PROMETHEUS_URL=http://prometheus:9090


   Then create the Prometheus config file:

   nano prometheus.yml


   Paste:

   global:
     scrape_interval: 15s

   scrape_configs:
     - job_name: 'prometheus'
       static_configs:
         - targets: ['localhost:9090']


   Launch the stack:

   docker-compose up -d


3. Configure Nginx Reverse Proxy

   Replace coroot.example.com with your real domain.

   sudo nano /etc/nginx/sites-available/coroot


   Paste the following:

   server {
       listen 80;
       server_name coroot.example.com;

       location / {
           proxy_pass http://localhost:8080;
           proxy_http_version 1.1;
           proxy_set_header Upgrade $http_upgrade;
           proxy_set_header Connection 'upgrade';
           proxy_set_header Host $host;
           proxy_cache_bypass $http_upgrade;
       }
   }


   Enable it:

   sudo ln -s /etc/nginx/sites-available/coroot /etc/nginx/sites-enabled/
   sudo nginx -t
   sudo systemctl reload nginx


4. Install Let’s Encrypt SSL

   Run Certbot for your domain:

   sudo certbot --nginx -d coroot.example.com


   Follow the prompts to install the SSL certificate.

   Certbot will automatically update your Nginx config with HTTPS and renewal.

5. (Optional) Auto-Renewal Test

   Ensure Certbot renewals work:

   sudo certbot renew --dry-run


6. Final Access

   Now you can securely access Coroot at:

   https://coroot.example.com


Troubleshooting

Add HTTP Basic Authentication to Coroot (via Nginx)

1. Install Apache utils (for htpasswd)

   sudo apt install apache2-utils


2. Create a Password File

   This will create the user admin. You can change the username.

   sudo htpasswd -c /etc/nginx/.htpasswd admin


   You’ll be prompted to enter a password.

3. Update Nginx Config

   Edit the Coroot Nginx site config:

   sudo nano /etc/nginx/sites-available/coroot


   Update the location / block like this:

   location / {
       auth_basic "Restricted Access";
       auth_basic_user_file /etc/nginx/.htpasswd;

       proxy_pass http://localhost:8080;
       proxy_http_version 1.1;
       proxy_set_header Upgrade $http_upgrade;
       proxy_set_header Connection 'upgrade';
       proxy_set_header Host $host;
       proxy_cache_bypass $http_upgrade;
   }


   Save and exit. Then:

   sudo nginx -t
   sudo systemctl reload nginx


Apply Firewall Rules with UFW

1. Enable UFW if Not Already

   sudo ufw enable


2. Allow Only Required Ports

   sudo ufw allow OpenSSH         # SSH
   sudo ufw allow 'Nginx Full'    # HTTP/HTTPS (80/443)


3. Deny Everything Else

   sudo ufw default deny incoming
   sudo ufw default allow outgoing


4. Status Check

   sudo ufw status verbose


Final Test

• Visit https://coroot.example.com — it should prompt for a username and password.
• Only ports 22, 80, and 443 should be accessible from outside.

Conclusion

Using this guide, you now know:

• ✅How to install Coroot on Ubuntu VPS
• ✅How to configure Coroot with reverse proxy and SSL encryption
• ✅How to add Http basic authentication and apply firewall rules using UFW
