How to Install DNSControl on Ubuntu VPS to Manage PowerDNS

This article demonstrates how to install DNSControl on Ubuntu VPS to Manage PowerDNS servers.

What is DNSControl?

DNSControl is an open-source system for managing DNS records across multiple providers using a single, version-controlled configuration.

Here’s what it does and why it’s useful:

Core Idea

Instead of manually creating and editing DNS records in each provider’s web UI, you write your DNS configuration once in a JavaScript-like file (dnsconfig.js). DNSControl then takes that file and synchronizes your records with any supported DNS providers (e.g., Cloudflare, Route53, PowerDNS, Google Cloud DNS, DigitalOcean, etc.).

Key Features

• Multi-provider support: Works with many DNS providers. You can even use multiple providers at once (primary/secondary or split-zone setups).
• Declarative configuration: Define what your DNS should look like in code, then run dnscontrol push to make it so.
• Version control: Since configs are just text files, you can store them in Git. This makes auditing, rollbacks, and collaboration easy.
• Consistency: Helps avoid drift and ensures your records are the same everywhere.
• Automation: Great for CI/CD pipelines—DNS changes can be tested, reviewed, and deployed like software updates.

Typical Workflow

1. Install DNSControl (a Go binary).
2. Write dnsconfig.js describing your domains, records, and providers.
3. Test with:

   dnscontrol preview

   (shows what changes would be applied).

4. Apply with:

   dnscontrol push

Example dnsconfig.js

var REG_NONE = NewRegistrar("none", "NONE");
var CF = NewDnsProvider("cloudflare", "CLOUDFLAREAPI");
D("example.com", REG_NONE, DnsProvider(CF),
A("www", "203.0.113.42"),
MX("mail", 10, "mail.example.com.")
);

This snippet says:

• Registrar is “none” (just a placeholder).
• DNS hosted at Cloudflare.
• Add an A record (www → 203.0.113.42).
• Add an MX record (mail → mail.example.com).

Below is a clean, repeatable setup you can run on an Ubuntu 22.04/Ubuntu 24.04 VPS to manage your PowerDNS Authoritative server via DNSControl (Stack Overflow’s “DNS as code” tool).

Prerequisites

• Ubuntu VPS with sudo access.
• A domain you can test with (e.g., example.com).
• PowerDNS Authoritative Server installed (we’ll install it below).
• Do all steps as a sudo-capable user.

How to Install DNSControl on Ubuntu VPS to Manage PowerDNS

To install DNSControl on Ubuntu VPS to manage PowerDNS, follow the steps below:

1. Install PowerDNS Authoritative Server (if you don’t have it yet)

   PowerDNS is available via apt. Choose a backend you like (SQLite, MySQL, or PostgreSQL). For quick starts, SQLite is simplest:

   sudo apt update sudo apt install -y pdns-server pdns-backend-sqlite3

   PowerDNS recommends installing via apt and adding a backend package; their docs cover Debian/Ubuntu specifics.

   If you prefer MySQL/MariaDB as backend:

   sudo apt install -y pdns-server pdns-backend-mysql

   (Several how-tos use pdns-backend-mysql on Ubuntu.)

2. Enable the PowerDNS HTTP API

   DNSControl talks to PowerDNS via its HTTP API.

   Edit /etc/powerdns/pdns.conf and add (or uncomment) these lines:

   # Enable the webserver + API webserver=yes webserver-address=127.0.0.1 webserver-port=8081 api=yes api-key=CHANGE_ME_TO_A_LONG_RANDOM_VALUE

   Restart PowerDNS:

   sudo systemctl restart pdns sudo systemctl status pdns --no-pager

   Test the API from the server:

   curl -H 'X-API-Key: CHANGE_ME_TO_A_LONG_RANDOM_VALUE' \ http://127.0.0.1:8081/api/v1/servers/localhost | jq .

   You should get JSON describing your PowerDNS server. (By default the server id is localhost.)

   Security tip: Keep the API bound to 127.0.0.1. If you must access it remotely, put it behind TLS and authentication (e.g., Nginx reverse proxy) and firewall it.

3. Install DNSControl

   You can either use a prebuilt binary or build with Go. The Go route is quickest and always current:

   1. Install Go (if you don’t have it):

      sudo apt install -y golang

   2. Install DNSControl:

      # Installs the latest v4 in your $GOBIN (usually ~/go/bin) go install github.com/StackExchange/dnscontrol/v4@latest

   3. Make sure dnscontrol is on your PATH:

      echo 'export PATH="$HOME/go/bin:$PATH"' >> ~/.profile source ~/.profile dnscontrol version

   (Official docs recommend go install .../v4@latest; binaries are also available on the GitHub Releases page.)

4. Create a DNSControl project

   mkdir -p ~/dnscontrol && cd ~/dnscontrol


   Create two files:

   1. creds.json

      This stores provider credentials. Use environment variables in creds.json when possible (supported by DNSControl) so you don’t commit secrets.

      { "powerdns": { "TYPE": "POWERDNS", "apiKey": "$PDNS_API_KEY", "apiUrl": "http://127.0.0.1:8081", "serverName": "localhost" } }

      Then export your key in the shell:

      export PDNS_API_KEY='CHANGE_ME_TO_A_LONG_RANDOM_VALUE'

      The provider expects API URL, API key, and server name (usually localhost).

   2. dnsconfig.js

      This is your “DNS as code” file. A minimal example for example.com:

      // @ts-check
      var REG_NONE = NewRegistrar("none");
      var DSP_PD   = NewDnsProvider("powerdns");  // matches the "powerdns" key in creds.json
      // Tell PDNS how to create the zone (if it doesn't exist):
      var PDNS_METADATA = {
      default_ns: [ "ns1.example.com.", "ns2.example.com." ],
      zone_kind:  "Native",          // or "Master"/"Slave"
      dnssec_on_create: false
      };
      D("example.com",
      REG_NONE,
      DnsProvider(DSP_PD),
      PDNS_METADATA,                 // merged as domain metadata (for PDNS zone creation)
      DefaultTTL("5m"),
      // records:
      A("@",  "203.0.113.10"),
      A("www","203.0.113.10"),
      MX("@", 10, "mail.example.com."),
      TXT("@", "v=spf1 -all")
      );


      • The PowerDNS provider supports metadata like default_ns, zone_kind, and dnssec_on_create when creating zones. (Metadata objects are merged into the domain when passed to D().)
      • The general JavaScript DSL reference is here.

5. Verify credentials and config

   # Verify that DNSControl can authenticate to PowerDNS:
   dnscontrol check-creds powerdns
   # Dry-run: show changes but do not apply them:
   dnscontrol preview --full


   • check-creds does a simple provider call using creds.json.
   • preview prints planned changes without touching DNS.

6. Push changes to PowerDNS

   When the preview looks right:

   dnscontrol push --full


   • push applies the changes to your PowerDNS via the API. (If the zone doesn’t exist, PDNS can create it using the metadata you supplied.)

7. Confirm in PowerDNS

   List zones via API:

   curl -H 'X-API-Key: '"$PDNS_API_KEY" \ http://127.0.0.1:8081/api/v1/servers/localhost/zones | jq '.[].name'

   (You can also script zone CRUD via the PDNS API; see /servers/{server_id}/zones endpoints.)

8. Migrating existing zones (optional)

   If you already run zones in PowerDNS (or elsewhere), you can bootstrap dnsconfig.js from live data:

   # Pull zones from a provider and output in dnsconfig.js-style: dnscontrol get-zones --format=djs powerdns - all > pulled-zones.djs

   Review and merge into dnsconfig.js. (See “Migrating zones to DNSControl”.)

9. CI/CD & production tips (optional but recommended)

   • Keep dnsconfig.js in Git; run dnscontrol preview on PRs and push on merges (GitHub Actions/Docker image are available).
   • Never commit real API keys; use env vars or a secret manager.
   • See the official “Getting Started” for more examples and commands.

Troubleshooting

• 401 Unauthorized from curl/check-creds: Wrong api-key or wrong value exported in PDNS_API_KEY. Ensure DNSControl’s apiUrl and serverName match your PDNS instance (localhost is the default server id).
• dnscontrol not found: Ensure ~/go/bin is in your PATH after go install.
• Zone creation didn’t happen: Ensure you included PDNS metadata (e.g., default_ns, zone_kind) with the D() call, and re-run preview/push.

Why this stack?

• DNSControl gives you “DNS as code” (versioned, reviewable changes) and a safe preview step before applying.
• PowerDNS provides a robust authoritative DNS with a solid HTTP API that DNSControl talks to directly.

Conclusion

You now know how to install DNSControl on Ubuntu VPS to manage PowerDNS.
