🚀 Deploy Elastic Stack on Ubuntu VPS (5 Minute Quick-Start Guide)

Here’s the guide to deploy Elastic Stack on Ubuntu VPS, with secure access, HTTPS proxying, and service optimization.

What is Elastic Stack?

Also known as ELK Stack, the Elastic Stack is a collection of tools for securely taking data from any source and format to search, analyze, and visualize it. The core components are Elasticsearch (a search and analytics engine), Kibana (for visualization), Beats (data shippers), and Logstash (a data ingestion pipeline). It is widely used for use cases like log management, security, observability, and business analytics.

🧭 Full Guide: Deploy Elastic Stack on Ubuntu VPS

✅ Works on Ubuntu 22.04 LTS or later

The Elastic Stack (formerly ELK Stack) consists of:

• Elasticsearch – data storage and search engine
• Logstash – data ingestion and processing pipeline
• Kibana – web-based data visualization and management UI

⚙️ Prerequisites

• Ubuntu VPS (with fresh install of 22.04+)
• At least 4 GB RAM, 2 vCPUs minimum
• Root or sudo access
• Open ports (see: How to Open Ports on Linux Server)
  • 9200 (Elasticsearch)
  • 9300 (Elasticsearch transport)
  • 5601 (Kibana)
  • 5044 (Logstash input)
• Optional: domain name for HTTPS proxying (e.g., search.example.com)

How to Deploy Elastic Stack on Ubuntu VPS

To deploy Elastic Stack on Ubuntu VPS, follow the steps outlined below:

1. 🧩 System Update

   sudo apt update && sudo apt upgrade -y
   sudo apt install apt-transport-https wget curl gnupg ufw -y


2. 🔑 Add Elastic APT Repository

   Import the GPG key and repository:

   curl -fsSL https://artifacts.elastic.co/GPG-KEY-elasticsearch | sudo gpg --dearmor -o /usr/share/keyrings/elastic-archive-keyring.gpg
   echo "deb [signed-by=/usr/share/keyrings/elastic-archive-keyring.gpg] https://artifacts.elastic.co/packages/8.x/apt stable main" | sudo tee /etc/apt/sources.list.d/elastic-8.x.list
   sudo apt update


3. 🧱 Install Elasticsearch

   sudo apt install elasticsearch -y


   Configure Elasticsearch

   Edit /etc/elasticsearch/elasticsearch.yml:

   cluster.name: elastic-stack
   node.name: node-1
   network.host: 0.0.0.0
   http.port: 9200
   discovery.type: single-node


   Enable and start the service:

   sudo systemctl enable elasticsearch
   sudo systemctl start elasticsearch
   sudo systemctl status elasticsearch


   Test Elasticsearch

   curl -k https://localhost:9200 -u elastic


4. ⚡ Install Logstash

   Logstash processes logs and sends them to Elasticsearch.

   sudo apt install logstash -y


   Configure Logstash Pipeline

   Create a configuration file:

   sudo nano /etc/logstash/conf.d/01-logstash-input.conf


   Example configuration:

   input {
     beats {
       port => 5044
     }
   }

   filter {
     grok {
       match => { "message" => "%{COMMONAPACHELOG}" }
     }
   }

   output {
     elasticsearch {
       hosts => ["https://localhost:9200"]
       index => "logs-%{+YYYY.MM.dd}"
       user => "elastic"
       password => "your_elastic_password"
       ssl => true
       cacert => "/etc/elasticsearch/certs/http_ca.crt"
     }
   }


   💡 You can use the generated CA certificate from /etc/elasticsearch/certs/ (Elasticsearch 8.x automatically generates one).

   Enable and start Logstash:

   sudo systemctl enable logstash
   sudo systemctl start logstash
   sudo systemctl status logstash


5. 🖥 Install Kibana

   sudo apt install kibana -y


   Configure Kibana

   Edit /etc/kibana/kibana.yml:

   server.port: 5601
   server.host: "0.0.0.0"
   elasticsearch.hosts: ["https://localhost:9200"]
   elasticsearch.username: "kibana_system"
   elasticsearch.password: "your_kibana_password"
   server.publicBaseUrl: "https://your-domain.com"


   Enable and start Kibana:

   sudo systemctl enable kibana
   sudo systemctl start kibana


   Access it via:

   http://your-server-ip:5601


6. 🌐 Secure with Nginx Reverse Proxy + HTTPS (Certbot)

   Install Nginx and Certbot:

   sudo apt install nginx certbot python3-certbot-nginx -y


   Create proxy configuration:

   sudo nano /etc/nginx/sites-available/kibana.conf


   Add:

   server {
       listen 80;
       server_name your-domain.com;

       location / {
           proxy_pass http://localhost:5601;
           proxy_set_header Host $host;
           proxy_set_header X-Real-IP $remote_addr;
           proxy_http_version 1.1;
           proxy_set_header Upgrade $http_upgrade;
           proxy_set_header Connection 'upgrade';
       }
   }


   Enable and secure:

   sudo ln -s /etc/nginx/sites-available/kibana.conf /etc/nginx/sites-enabled/
   sudo nginx -t && sudo systemctl reload nginx
   sudo certbot --nginx -d your-domain.com


   Now, Kibana will be accessible securely via:

   https://your-domain.com


7. 📊 Connect Beats (Optional)

   To ship logs from other systems, install Filebeat:

   sudo apt install filebeat -y


   Configure /etc/filebeat/filebeat.yml:

   output.logstash:
     hosts: ["your-vps-ip:5044"]


   Then enable and start:

   sudo systemctl enable filebeat
   sudo systemctl start filebeat


8. 🧠 Verify Stack Connectivity

   Check that all services are communicating:

   sudo systemctl status elasticsearch
   sudo systemctl status logstash
   sudo systemctl status kibana


   Then in Kibana:

   • Visit Stack Management → Index Patterns
   • Confirm indices like logs-* are appearing.

9. ⚙️ Optional JVM Optimization

   Edit heap size settings for performance:

   sudo nano /etc/elasticsearch/jvm.options.d/custom.options


   Add (50% of available RAM recommended):

   -Xms2g
   -Xmx2g


   Restart services:

   sudo systemctl restart elasticsearch logstash kibana


10. 🛡 Secure and Maintain

    • Use ufw to limit access to ports:

      sudo ufw allow 5601,9200,5044/tcp
      sudo ufw enable


    • Regularly update:

      sudo apt update && sudo apt upgrade -y


    • Monitor logs:

      sudo journalctl -u elasticsearch -f
      sudo journalctl -u logstash -f
      sudo journalctl -u kibana -f


✅ Final Verification

Open:

https://your-domain.com

Log in with your Elastic superuser credentials and confirm:

• Elasticsearch cluster health = green
• Logstash pipelines visible
• Indices showing in Kibana → Discover

🎯 Summary

You now have a fully functional Elastic Stack running securely on your Ubuntu VPS — ideal for central log management, data analytics, and real-time search.

Conclusion

You now know how to deploy Elastic Stack on Ubuntu VPS.
